27" Wall Mount Touch All-in-One PC
Large-Screen Touch Computing for Wall-Mounted Applications.
Bring interactive computing to walls, counters and public spaces with a 27-inch touch all-in-one PC. Combining a large PCAP touchscreen, integrated computing platform and slim aluminum enclosure, this system is designed for applications that require a large interactive display without a separate external PC.
27-Inch Touch All-in-One PC for Flexible Installation
The MotiveTouch 27″ Wall Mount Touch All-in-One PC combines a large-format touchscreen with a built-in computer in a compact, wall-mountable design.
Its 27-inch display provides more interactive space for applications such as self-service kiosks, digital signage, hospitality, healthcare, education and smart building systems.
The integrated computing architecture eliminates the need for a separate external computer, helping system integrators simplify installation, reduce equipment footprint and create cleaner product designs.
Key Features
12th Gen Intel Processor
High-performance, fanless 12th generation Intel® Alder Lake processor delivers reliable computing performance for demanding applications.
9–36V Wide Voltage Input
Designed with an aluminum alloy enclosure and supports 9–36V wide-voltage DC input for flexible integration into different power environments.
Rich I/O Connectivity
Equipped with 4 serial ports, 6 USB ports, and 2 network ports for flexible connectivity with peripherals, controllers, and network devices.
3mm Tempered Glass & IP65
The 3mm physically tempered glass provides enhanced protection against accidental impact, and the front IP65 protection.
Ultra-Narrow Bezel Design
Industry-leading ultra-narrow bezel design maximizes the active display area while providing a sleek and compact appearance.
Fanless Computing Design
The fanless architecture eliminates the need for a cooling fan, helping reduce noise, dust accumulation, and mechanical maintenance.
Technical Specification
| Screen Size | 27 inch |
| Visible Area | 597.6 x 336 mm |
| Resolution | 1920 x 1080 @60Hz |
| Aspect Ratio | 16 : 9（standard） |
| Viewing Angle | 178°H/V |
| Brightness | LCD panel： 300 nits， Touch Pcap： 270 nits |
| Contrast Ratio | 3000 : 1 |
| Backlight Lifespan | 30,000 hrs |
| Touch Technology | Projected Capacitive Touch (PCAP) |
| Number of Touch Points | 10-point Touch (Under Windows 7/10/11) |
| Cover Glass | 3mm physically tempered (silk print), (optional: AG/AR |
| CPU | Intel N97, 2.0G Hz, up to 3.6G Hz |
| Intel i3-1215U, 1.2G Hz, up to 4.4G Hz | |
| Intel i5-1235U, 1.3G Hz, up to 4.4G Hz | |
| Intel i7-1255U, 1.7G Hz, up to 4.7G Hz | |
| Memory | DDR4 8G, up to 64G |
| Storage | 128G SSD default, up to 1TB |
| WIFI | WIFI + BT |
| Ethernet | 2 x Intel GBE LAN chip, 10/100/1000 Mbps, RJ45 port |
| USB Port | N97: 4xUSB 3.0 + 2xUSB 2.0 |
| i3/i5/i7: 6xUSB 3.0 | |
| Videot Output | 1xHDMI + 1xDP |
| Serial Port | 1xRS 485(RS 232 is optional), 3xRS 485/RS 232 |
| Operating System | Win 10, Win 11, Linux |
| Input Voltage | DC 9~36V (3P-5.08 Phoenix Connector) |
| Housing Material | Aluminum alloy housing |
| Overall Dimensions | 654.1x 392.7x 59 mm |
| VESA | 100 x 100 mm M4 VESA |
| Net Weight | 9.2 KG |
| Operating Temperature | 0 ~ 50℃ |
| Storage Temperature | -20 ~ 60℃ |
| Waterproof | Front Panel IP65 Protection Rating |
| Operating Hours | 7 x 24 hours |
| Certifications | CE， FCC， CCC |
Why Choose a 27" Touch All-in-One PC?
A 27-inch touch all-in-one PC offers a balance between screen visibility, interactive space and installation flexibility.
Compared with smaller touch computers, the larger display provides more room for detailed interfaces, menus, dashboards and multimedia content. At the same time, the all-in-one design keeps the computer and touchscreen integrated into a single system.
27″ is a practical choice for applications that need more interactive screen space without moving to an oversized commercial display.
Applications
Kiosk & Self-Service
Large-screen touch interaction for self-service kiosks, check-in terminals, ordering systems and information kiosks.
Hospitality
Ideal for hotel check-in, guest information, interactive directories and other hospitality applications.
Transportation
Touch computers for transportation terminals, passenger information systems, ticketing and fleet management.
Digital Signage
Interactive digital signage for retail, hospitality, transportation and public spaces.
Built for OEM Integration
Need a touch computer designed around your application?
MotiveTouch provides OEM and ODM customization for the 27″ Wall Mount Touch All-in-One PC, helping system integrators and equipment manufacturers create application-specific touch computing solutions.
OEM customization options may include:
- Custom branding and logo
- Hardware configuration
- Memory and storage options
- Operating system configuration
- I/O customization
- Mounting and enclosure modifications
- Custom software or pre-installed applications
Frequently Asked Questions
What is a 27" Wall Mount Touch All-in-One PC?
A 27″ Wall Mount Touch All-in-One PC combines a 27-inch touchscreen, display and integrated computer into a single wall-mountable system. It is designed for interactive applications where space efficiency and touch operation are important.
What applications are suitable for a 27" touch all-in-one PC?
A 27-inch touch all-in-one PC is suitable for kiosks, self-service terminals, digital signage, hospitality, healthcare, education, banking, transportation and smart building applications.
What is the warranty year?
MotiveTouch provides 1-year as a standard free warranty service.
Can the 27" Wall Mount Touch All-in-One PC be customized?
Yes. Depending on project requirements, customization options may include processor configuration, memory, storage, operating system, I/O interfaces, mounting solutions, touchscreen specifications and enclosure design.
Can MotiveTouch provide OEM or ODM solutions?
Yes. MotiveTouch can work with OEMs, kiosk manufacturers and system integrators on customized touch computing solutions based on application and integration requirements.
Looking for a 27" Wall Mount Touch All-in-One PC?
Whether you need a standard configuration or an OEM touch computer designed for your equipment, our team can help you select the right display, computing platform, mounting solution and I/O configuration.
