21.5" High Brightness Touch Monitor
500 Nits FHD PCAP Touchscreen for Bright Indoor and Industrial Applications.
Designed for bright indoor environments and demanding commercial or industrial applications, the MotiveTouch 21.5″ High Brightness Touch Monitor delivers a clear Full HD 1920×1080 display with 500 nits brightness and responsive PCAP multi-touch.
Its large 21.5-inch screen provides an intuitive interactive interface for industrial HMI, automation equipment, kiosks, self-service terminals, digital signage, and OEM systems.
21.5" High Brightness Touch Monitor for Clear Interactive Applications
The MotiveTouch 21.5″ High Brightness Touch Monitor combines a large Full HD display with a responsive projected capacitive touchscreen to provide a clear and intuitive interactive experience.
With 500 nits brightness, the display is designed for environments where standard-brightness monitors may appear less visible, including bright production areas, commercial spaces, kiosks, self-service terminals, and equipment control stations.
The 21.5-inch 16:9 screen provides a spacious workspace for HMI interfaces, dashboards, menus, control panels, and interactive applications, while PCAP multi-touch enables smooth and intuitive operation.
Key Features
500 Nits High Brightness
Enhanced display brightness provides improved visibility in bright indoor environments and commercial or industrial workspaces.
Full HD 1920×1080 Resolution
The 21.5-inch FHD display delivers detailed images, clear text, and a spacious 16:9 viewing area.
3mm Tempered Cover Glass
Durable 3mm physical tempered glass provides enhanced protection against accidental impacts.
IP65 Front Protection
IP65-rated front panel protection helps protect against dust and water ingress.
Industrial-Grade Design
Built for integration into industrial equipment, kiosks, control panels, and other professional systems requiring reliable touchscreen operation.
OEM-Friendly Design
Designed for system integrators and OEMs requiring a reliable display solution for custom equipment and enclosures.
Technical Specification
| Screen Size | 21.5 inch |
| Visible Area | 476.6 x 268.1 mm |
| Resolution | 1920 x 1080 @60Hz |
| Aspect Ratio | 16 : 9（standard） |
| Viewing Angle | 178°H/V |
| Brightness | LCD panel： 500 nits； Touch Pcap： 400 nits |
| Contrast Ratio | 1000 : 1 |
| Backlight Lifespan | 30,000 hrs |
| Touch Technology | Projected Capacitive Touch (PCAP) |
| Number of Touch Points | 10-point Touch (Under Windows 7/10/11) |
| Cover Glass | 3mm physically tempered (silk print), (optional: AG/AR |
| I/O interfaces | 1*USB-B（Touch） |
| 1*VGA | |
| 1*HDMI （Type-A） | |
| 1*DP | |
| Overall Dimensions | 532.3 x 323.7 x 51.5 mm |
| VESA | 100 x 100 mm M4 VESA |
| Net Weight | 6.6 KG |
| Operating Temperature | 0 ~ 50 ℃ (32 ~ 122°F) |
| Storage Temperature | -20 ~ 60℃（-4 ~ 140°F） |
| Waterproof | Front Panel IP65 Protection Rating |
| Operating Hours | 7 x 24 hours |
| Certifications | CE， FCC， CCC |
Application
Vending Machines
Large touchscreen interfaces for product selection, payment, and user interaction.
Self-Service Kiosks
A large interactive display for self-service terminals, information kiosks, and customer-facing systems.
Reverse Vending Machine
The touchscreen can provide a clear interactive interface for reverse vending machines and automated recycling systems.
Security & Access Control
Interactive displays for visitor management, access control, and security terminals.
Built for OEMs, Integrators and Equipment Manufacturers
The 21.5″ High Brightness Touch Monitor is designed for OEMs, system integrators, kiosk manufacturers, automation companies, and equipment manufacturers looking for a reliable touchscreen display platform.
Whether integrated into an industrial control panel, self-service kiosk, vending machine, smart locker, or commercial equipment, the display provides a large interactive interface with 500-nit brightness and Full HD resolution.
Available customization options may include:
- Display brightness
- Resolution
- PCAP or resistive touch
- Cover glass
- Anti-glare treatment
- Optical bonding
- Touch sensitivity
- Video interfaces
- Touch interface
- Mounting structure
- Enclosure design
- Cable length
- Logo / branding
- Operating temperature
- Power input
Tell us your application, installation dimensions and required interfaces, and our engineering team can recommend a suitable configuration.
Frequently Asked Questions
What is the brightness of the 21.5-inch touch monitor?
The MotiveTouch 21.5-inch High Brightness Touch Monitor provides 500 nits brightness, offering improved visibility compared with standard-brightness displays in bright indoor and commercial environments.
Is the 21.5-inch 500-nit monitor sunlight readable?
No. This model is designed as a 500-nit high brightness touch monitor, not a dedicated sunlight-readable display. It is better suited for bright indoor, commercial, industrial, and other controlled-lighting environments.
What is the warranty year?
MotiveTouch provides 2-years as a standard free warranty service.
Can this monitor be customized for OEM applications?
Yes. OEM customization can be available depending on project requirements, including mounting structure, cover glass, touch configuration, housing, interfaces, and other integration options.
What operating systems does the touchscreen support?
The touchscreen can be integrated with operating systems such as Windows, Linux, and Android, depending on the selected touch controller and project configuration.
Get a 21.5" High Brightness Touch Monitor for Your Project
MotiveTouch can help you select or customize the right 21.5″ high brightness touch monitor for your application.
